COB Module 1 LED Strip Light IP65 Club Bright Billboard Lamp DC 12V
Description of the connection between modules:
1 :Find the end of the wire, cut a length of cover about 5cm (do not cut the copper wire, only cut the cover)
2 : Connect two strip light , make sure the copper wire are fully contact to each other. (please confirm the negative and positive is right)
3 : Use the insulating tape surrounding the connecting position to prevent the electric leakage
The Modle Kits Connection:
Step 1: remove the remote battery insulation film, check the remote batter is connected.
Step 2: Connect the LED and mini DC adapter with a screwdriver, attention to positive and negative pole.
Step 3: Separate LED strip. Connect the remote and plug. Finish! Good job.
Features:
Commercial advertisement signs backlight
Channel letters backlight store front light
Advertisement light box backlight & decoration sign
Ideal replacement of incandescent and fluorescent lights
LOGO advertising billboard, exposed luminous characters
Suitable for boat cabin & deck lighting, stair, kitchen, courtesy, caravan, garden etc.
Note :
-20pcs led module each string, they can also be cut off on customer's requirement, be sure you cut the connect line between the strip.
- We do not take responsibility for the installation,please let the profession man to install.
Module Specifications:
Type: COB module
Material: PVC Plastic
Standard Cascade: 20COB one set
Beam angle: 160 degree
Waterproof level: IP65
Working Voltage: DC 12V
Power: 2.4W / each strip
Lumen: 200lm / each strip
Dimension: 43*28*4mm / 1.7 * 1.1 * 0.2 inch (each strip)
Total length of each module set with extension wire: 3m / 10ft
Optional color: As picture shows
Working Temperature: -20~60℃
Note:
-Please allow 1-3cm(0.4-1.2inch) differs due to manual measurement.
-Due to the different display and different light, the picture may not reflect the actual color of the item. Please understand.
Package included:
1 x COB 1 LED module
